30 Amp MPPT Solar Charge Controller (MC Series)

This MC Series-30 Amp MPPT Solar Charge Controller protects your batteries (lead-acid, colloidal, vented or lithium) from overcharging with automatic temperature compensation and MPPT (Maximum Power Point Tracking) technology achieving 99% Efficiency.

Note: For Data Monitoring and Custom Setting Modification, either a Solar Remote Display or Bluetooth Module is recommended.

Accessories

Optional Accessories for data monitoring and custom settings:

• Solar Remote Display
• Bluetooth Module

Specifications

This model comes with automatic identification of lead-acid battery voltage and come with pre-programmed charging algorithms for gel, sealed and Lithium batteries. It also features an overheat protection, automatic charging voltage regulation function and a limited charging mode for extra component protection and to ensure maximum system performance. The Controller is also protected by solar panel short circuit protection, battery open circuit protection and TVS lightening protection.

The Charge Controller is intended to be used with a either a Remote Display or BT Module to check operating data and status while being able to modify controller parameters. This controller comes with a standard Modbus protocol and meets different communication needs.

DOWNLOAD OWNERS MANUAL
